Sensor head is bidirectional and rotatable in 15° increments

NEMA ICS5-2000

N/O – Switch Function

RoHS

Input

Voltage: 90 - 250 VAC/45-65Hz
Frequency: 0 - 25Hz
Power Consumption: ≤1.7 mA

Output

Type: Normally Open (NO)
Voltage Drop:: ≤5 V
Max Load Current:: 8-400ma

Physical

Operating Temp: -25°C to +70°C
Housing: PBT/Aluminum

Sensing

Sensing Distance:: 15mm
Repeatability:: ≤.01mm
Hysteresis:: 3-15% (5% Typical)
Switching Freq:: 0 - 25Hz
